Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant

    Buy cheap Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant from wholesalers

    Buy cheap Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant from wholesalers
    • Buy cheap Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant from wholesalers
    • Buy cheap Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant from wholesalers

    Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant

    Ask Lasest Price
    Brand Name : SUNTEX
    Model Number : GF430P-PE133-8003
    Payment Terms : T/T; L/C, Paypal...
    Supply Ability : 500000sqm/month
    Delivery Time : 5-20 days
    • Product Details
    • Company Profile

    Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant

    Twill Weave PTFE Coated Fiberglass Fabric High Temperature Resistant


    PTFE Coated Fiberglass Fabric use best imported Fiberglass yarn as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE fabricin different thickness and widths.


    PTFE Coated Fiberglass Fabric applications

    - Thermal insulation jacket, mattress and pad

    - Expansion joints and compensators

    - Conveying belt


    BASE FABRICBase fabric style No. GF430P
    (metric)(English)Test methods
    Weave4H SatinCrowfoot
    Yarn
    WarpEC9 136 1﹡0ECG 37 1/0
    WeftEC9 136 1﹡0ECG 37 1/0
    Construction
    Warp18 ± 1 ends/cm48 ± 3 ends/inchASTM D 3775-96
    Weft12.6 ± 1 picks/cm32 ± 3 picks/inchASTM D 3775-96
    Weight430 ± 30 g/m212.6 ± 0.9 oz/yd2ASTM D3776-96
    Thickness0.37 ± 0.06 mm0.015 ± 0.002 inchASTM D1777-96

    COATED FABRICCoating style No. PTFE133-8003
    CoatingPTFE coated on one side
    Weight580 ± 20 g/m217 ± 0.6 oz/yd2ASTM D3776-96
    Thickness0.43± 0.02 mm0.016 ± 0.0007 inchASTM D1777-96
    ColorGrey
    Fire resistanceFlame retardant
    Temp resistance

    Glass fabric up to 5500C (10000F)

    PTFE coating up to 3300C (6200F)

    white ptfe fiberglass fabric

    Related Style

    -_03-_04-_01-_02-_05-_12-_14-_16-_15

    1. Q: Are you a factory or trading company?

    A: We are a factory.


    2. Q:Why do you choose us?

    A: Suntex management and staff have over 20 years of cumulative experience in industrial textiles.


    3. Q:What is your delivery time?

    A:Generally we will within 30 days of delivery to you


    4. Q:Can you product the customized goods?

    A:Surely, we can be customized according to your demanding.


    5. Q:What kinds of payment you accept?

    A:We accept T/T, L/C ,D/P or other.


    6. Q:Do you have other production?

    A:Certainly,we still have Rewettable fiberglass fabric, EPDM rubber coated fiberglass fabric, Fluoride coated fiberglass

    fabric, Hypalon coated fiberglass fabric, PVC coated fiberglass fabric, PVC coated polyester fiberglass Carbonized fabric,

    Aluminized aramid fabric . We are looking forward to your enquiry.
